LCD Screen
LCD splicing screen-Video wall-Monitoring display
Super Narrow Beze
Achieve a sensational virtually seamless video wall thanks to our video wal panels that have a total bezel size of just 3.5mm. This allows your content to take center stage and provides avisual experience to remember for anyone who sees the dispaly.
Automatic Tiling
Our Video Walls Displays offer the ultimate in versatility. With a hassle free setup it is easy for our Video Wall Displays to tile the video signal automatically thanks to their integrated video matrix processor. This means that no additional matrix processing hardware is required. reqardless of the configuration of your video wall.
IPS Panel
State of the art commercial grade IPS panels give our video walls superior colour uniformity,a large viewing angle and remarkably vibrancy,even when mounted in portraot.Also these panels do not suffer from blackening defect when usde as a window dispaly.
Multiple Configurations
These displays can be used to create video walls of any configuration, for example 2x2, 3x3, 1x4, 5x3 etc. Whatever your configuration requirements these displays can support them, even if you want a portrait video wall.
Commercial Grade
Designed for use in commercial applications, Video Walls can run 24/7.
Environmentally Friendly Power Timer
Allows for a reduced power use age in those hours that the displays are not required. Set daily or weekly On/Off times for your displays.LCD splicing screen - video wall - monitor display - conference room, we professional provide LCD display, after formal certification, product guarantee!
| Model | LCD video wall | ||
| Panel | Display Size(inch) | 46" | 55" |
| Resolution | 1920x1080 (16:9) | 1920x1080 (16:9) | |
| Active Display Area(mm) | 1015(H) x569(V) | 1209.6(H) x 680.4(V) | |
| Aspect Ratio | 16:09 | 16:09 | |
| Brightness(cd/m2) | 500nit | 500nit | |
| Contrast Ratio(Typ.) | 4000:1 | 4000:1 | |
| Viewing Angle(H/V) | 178:178 | 178:178 | |
| Color | Black | ||
| Bezel | 1.8mm | 1.8mm | |
| Response Time(G-to-G) | 6.5ms | 6.5ms | |
| Life time | 60,000hours | 60,000hours | |
| Pixel Pitch(mm) | 0.530(H) x 0.530(V) | 0.630(H) x 0.630(V) | |
| Response time | 8(Typ. G to G) | 8(Typ. G to G) | |
| Others | Source selection | RGB, DVI, HDMI, AV, USB |
| Power | Build-in type, 100 ~ 240V AC, 50/60 Hz | |
| Surface treatment | Powder coated | |
| Shell material | Cold-rolled sheet | |
| Screen position | Landscape (vertical is optional) | |
| Installation | Hooks | |
| Package | PE film, foam corner and honeycomb box | |
| Application | Indoor | |
| Accessories | HDMI cable*1, RJ45 cable*1, remote control*1, IR sensor*1, driver USB disk*1,DP cable*1 |
ORDERING FROM US
At lcdkiosk, Our goal is to make your experience as smooth and hassle-free as possible, ensuring that you receive a high-quality product that meets your expectations. From project evaluation to after-sales service, we ensure that each step is carefully executed to meet your requirements. Here are the steps to follow:
Step 1
Project Evaluation (1-2 days)
The first step is to evaluate your project requirements and expectations. We have a dedicated team that will work closely with you to understand your needs, answer any questions you may have, and provide expert guidance. This evaluation process typically takes 1-2 days to gather all the necessary information.
Step 2
Sample Production (7-30 days)
Once the project evaluation is complete and payment is received, our skilled production team will manufacture samples according to your specifications. This process may take anywhere from 7 to 30 days, depending on the complexity of the product and the availability of materials. We prioritize maintaining high-quality standards during this phase.
Step 3
Confirm the Product and Pack It (1-2 days)
After the sample is made, we support inspection. We encourage you to check the samples thoroughly, Once the product design and quality meet your expectations, we will proceed with packing the final order. This step generally takes 1-2 days to ensure that everything is securely packaged.
Step 4
Shipping (7-45 days)
When the product is packed and ready for shipment, We offer a variety of shipping options to meet your needs. If you’re in a hurry, air shipping is the fastest but more expensive option, taking just 7-10 days. Sea shipping is the most economical but takes longer, at 30-45 days. We will provide you with a more accurate estimate based on your specific destination and any customs procedures involved.
Step 5
After Service
Our commitment doesn’t end with the delivery of your order. We value our relationship with customers and offer comprehensive after-sales service. If you encounter any issues or have any questions regarding the product, our dedicated support team is ready to assist you. We prioritize customer satisfaction and strive to address any concerns promptly and effectively.
